MAKE: CREATIVE LAB
MODEL: CLFM-07
DESCRIPTION:
It consists of a tank provided with inlet supply diffuser, overflow. Provision for fitting Orifice or mouthpiece at the outlet of tank. An arrangement is done to vary head and keep it constant at desired level. A pointer gauge arrangement for measuring X-Y co-ordinates of Jet is also fitted. Present set-up is self-contained water re-circulating unit, provided with a sump tank and a centrifugal pump etc. Flow rate of water is measured with the help of measuring tank and stop watch.
EXPERIMENTATION:
To determine the co-efficient of discharge of different Orifice and mouthpieces.
To determine the co-efficient of velocity
UTILITY REQUIRED
Water Supply.
Drain.
Electricity 0.5 kW, 220 V AC, Single Phase.
Floor Area 1.5 x 0.75 m.
TECHNICAL SPECIFICATION
Set of Orifices Material Acrylic (2 Nos.)
Dia. 10mm and 15 mm
Set of Mouthpieces Material Acrylic (3 Nos.)
Dia 10 mm (L/D = 1) Dia 10 mm (L/D = 2.5) Dia 10 mm (L/D = 4)
Constant Head tank 35 Ltrs.
Pointer Gauge To measure X-Y co-ordinates of Jet.
Water Circulation FHP Pump, Crompton make.
Flow Measurement Using Measuring Tank with Piezometer, Capacity 25 Ltrs.
Sump Tank Capacity 70 Ltrs.
Stop Watch Electronic.
Control Panel Comprises of Standard make On/Off Switch, Mains Indicator, etc.
Tanks will be made of Stainless Steel.
The whole set-up is well designed and arranged in a good quality painted structure.
Instruction manual will be provided along with the Apparatus.
|
