DESCRIPTION

As per the IS:2720 (Part 2) The speed of drying (about 30 min), The infrared radiation is controlled by a voltage regulator. The instrument is provided with an indicator lamp. The balance scale (drum) is divided in terms of moisture percentage on wet weight basis, which are read directly from it. Graduations are from 0 to 100% in 0.2 % divisions. Suitable for operation on 220 V, 50 Hz, Single phase, AC Supply. Capacity : min 5g approx. Sensitivity : min 10 mg approx. Range : 0 to 100% moisture content on wet weight basis. Reading accuracy : min ± 0.20% Probable error : min ± 0.25% in the lower range upto compared to 25% and ± 1% for moisture contents Oven methods : above 50% Equipment consisting of :- Infra Red Lamp Thermometer (L-shaped) .

Microprocessor based load frame 2 kN Capacity with proving ring and dial gauges ,with related software Ref. Standards IS :11229, 2720 (Part 13) Supplied complete with carriage, loading hanger and 10:1 lever loading device. Suitable for specimens of size 60×60×25mm. Membrane keypad and the 40×2 LCD display. Precision loading rate of 0.00001 to 9.99999mm / minute. Suitable for operation on 220 V, 50 Hz, Single phase, AC Supply. Microprocessor control Accepts specimen 60mm square Shear Box Assembly, This assembly comprises of : Halves of the Shear Box 2 Nos. Plane Gripper Plate - 2 Perforated Gripper Plate - 2 Porous Stone - 2 Top Loading Pad - 1 Base Plate - 1 Specimen Cutter - 1 Min normal stress - 3 kg/cm2 Operation : Motorised Variable Rates of Strain Specimen Size : 60 x 60 x 25 mm Compression - Tension Proving Min Ring, 2 kN capacity Dial Gauge - 2 .
